主要用途与简绍/Brief Introduction：

滤油机组为10-20ml服用方式液液滴分装研发线中的常见装备。是由洗瓶、真空干燥分离式化机和分装塑封分离式化机所形成，能定时成功完成服用方式液瓶的洗瓶、真空干燥、分装和塑封等舞蹈动作，是服用方式液研发制造厂更很好的专用设备配套装备，彻底不符合GMP规定。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

亮点/Characteristic：

◆装量精确较高，应对漏滴。灌装生产线表面粗糙较高。High filling accuracy.◆定频无级变频调速，生產流速可以调节，待选择有所差异的生產流速。Frequency control, production speed is adjustable, you can choose a different production rate.◆那些物品pcb板均选取德国出名店牌。All electrical components are imported famous brands.◆自动式表示记数性能。Automatically countting function.◆控住主要包括岛国三凌PLC，抗电磁波辐射，岗位平稳。Controlled by Mitsubishi PLC◆固定性固定，定期维护清洗便利。Stable performance, easy maintenance.◆整套装置表层进行SUS304不锈碳钢作、与物品玩地方进行316L不銹钢。整套装置完整按GMP的要求来设计。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

技艺基本参数/technical parameters：

适合要求/Bottle size	10-20ml
生产销售作用/Capacity	60-90瓶/分钟的时间/60-90bottles/min
烘干设备温度表/Dryer tempreture	100-300°
造纸废水处理水量/Water wastage	0.5m3/h
静化水耗量/Purifying water consumption	0.3m3/h
装量要求/Filling precision	≤1%
电源模块/Voltage	380V/50Hz
输出/Power	33KW
生育线总长/Dimension	3500×1500×1600mm
