领域与简洁/Purpose and introduction

该制造线由理瓶机(上瓶台)、超音波波洗瓶机，罐装(旋盖)加塞机，轧盖机，贴标签机等生产设备组成了On the production line by unscramble bottle machine (bottle), ultrasonic bottle washing machine, filling (screw cap) stoppering machine, rolling machine, labeling machine and other equipment

特质/characteristic：

该制作线适宜于 30-500ml系厂品的灌装工作线加塞密封，更新这些产品规格硅胶模具后，既适宜于泡沫塑料饮料瓶，也适宜于玻璃板瓶。具备着不适应的范围多，调正快捷的优势。整线制作程度；适玻璃瓶尺寸大小造型，物块消费黏性而定。The product line is suitable for 30-500 ml series products filling barging sealing, change some specifications after the mould, is suitable for plastic bottle, also suitable for glass bottle. Have to adapt to a wide range, convenient adjustment. The whole line production capacity; Optimum size bottle shapes, object on the viscosity.

新技术叁数/technical parameters：

生产能力production capacity(pcs/h)	80-120(8针灌装、6头轧盖    40-60(4针灌装、单头轧盖)
洗瓶清洁度Washing bottle cleanliness(%)	> 99
装量误差度The load error(%)	0-2
上塞通过率Plug on the percent of pass(%)	> 98
轧盖合格达标率Rolling cover percent of pass(%)	> 98
功率power(kw)	11
外形尺寸boundary dimension(LxWxH)   (mm)	9.740 × 1,470 × 1,785
