功用与百科/Brief introduction：

超声波焊接机是在引进技艺和吸收能力其他国家现代化技艺的知识基础上，我集团有意识的主动研发管理的几款的专业涉及西林瓶的灌装设备、上塞、旋（轧）盖机。超声波焊接机主要包括法国全出口品质兼优等级关闭式凸轮机构精确等级办公桌器，精确等级高，加载耐用，选用选用期长。该精确等级器结构特征很简单，经常选用不需要返修。机器主要适用人群于几种小摄入量溶液的罐装、压塞及旋（轧）盖，如按摩油、注射液体剂等。大范围使中用肉食品、医药矿业、矿业职业及科研管理范围。设施既可单机联机研发，又可与洗瓶机、太干机等设施组建联动机制研发线。充分具备发达国家GMP条件。机器会会按照客条件优化电力配置单。NFGX-5/50 Automatic Vial Filling&rotation (rolling) machine is built in the absorption of foreign advanced tecnology, based on independently developed by the company ,It is the domestic leading level.This machine is suitable for a variety of small doses of liquid filling&capping such as oil, injection . Widely used in food, pharmaceutical, chemical industries and scientific research.  Single machine can produce, but also with washing machine, dryer and other equipment linked production line. Full compliance with the GMP requirements. The machine according to customer requirements to upgrade the electrical configuration

优缺点/Characteristic:：

◆人机对战菜单栏调整、进行直接便于、PLC的控制，装量*。Human-machine interface settings, an easy and intuitive, PLC control, the amount of precision equipment. ◆定频把握、产生时间同时可以调节、手动计数法。Frequency control, the production rate be adjusted automatically count  ◆自动式停止时的功能，无瓶不分装。No bottle no filling.◆圆筒产品定位式罐装，稳定的可以信赖。Disc positioning filling, stable and reliable.◆高精准度凸轮机构量程计操纵，市场定位*。High-precision cam meter control, precise positioning.◆使用SUS304及316L铝合金创造，全达到GMP需求。SUS304 and 316L stainless steel, full compliance with GMP requirements.

技术设备指标/ technical parameters：

装量範圍Filling volume	5-50ml
装量出现偏差的原因loading error	≤ ±1%
旋（轧）盖合格证率 Rotation (rolling) Cover pass rate:	≥99%
出生产意识力Production capacity	30-60瓶/分 钟&nbs🍷p; 低速度 70-100瓶/分 钟     快速路 30-60 bottles / min  70-10𒐪0 bottles / minute (high speed)
压塞率Tamponade rate	≥99%
开关电源 Power	380V/50Hz
输出功率Power	2.0 kw
机气净重量Net weight	600 kg
外貌尺寸规格 Dimension	2000*1000*1500mm
